Alpha Hot-Rod Channel Cutting Granite Blades - 3"

The Alpha Hot-Rod Granite Blade is designed for cutting channels on the underside of countertops for reinforcing rods. (1/4", 1/8", and 3/16" blade cut sizes available)
As low as $85.50

Availability: Sold In Store - Ships From Store (More Info)

Shipping: Free to Continental US (More Info)

Only %1 left
SKU
T-ALPH HR

Alpha Hot-Rod Channel Cutting Granite Blade for 1/4'' Support Rods:
Alpha developed a revolutionary way to improve the efficiency of fabricators. For years, slab fabricators have employed labor-intensive procedures for creating channels in the underside of countertops to accommodate stainless steel reinforcing rods at sink and cooktop cutouts. Alpha recognized the opportunity for improvement and developed the Alpha Hot-Rod Blade.

With the Alpha Hot-Rod Blade attached to the Alpha AWS-110 or AWS-125 Wet Stone Cutter, a fabricator can accomplish the task in one easy pass.The Hot-Rod for Granite blades were created with diamond grits and matrix best suited for all categories of granite, including hard red granites, to assure a long cutting life. With a 3" diameter, the blade allows for easy use and better leverage when cutting 1/4" deep channels, by allowing for better positioning of the stone cutter's handle. This blade is now available in three thicknesses: 1/4" for standard rods, 1/8" for thinner rods and 3/8" for threaded rods.

The Hot-Rod for Marble applies the same technology but is designed for softer stones such as marble. For efficient creation of channels for reinforcing rods, attach this unique blade to our AWS-110 or AWS-125 for a smooth, dust-free operation. Used in this manner, productivity will increase significantly. Although Alpha recommends wet cutting, these blades may be used wet or dry.

Recommended for 1/4" rods. 7/8" Arbor

Alpha Hot-Rod Channel Cutting Granite Blades Specifications:

Part No. Size Thickness Maximum RPM Arbor(s) Recommended For
HT03A+ 3" 4.2mm/.165" 14,500 7/8", 20mm 1/8" Rod
HQ03A+ 3" 5.5mm/.216" 14,500 7/8", 20mm 3/16" Rod
HR03A+ 3" 7mm/.275" 14,500 7/8", 20mm 1/4" Rod
HW03A+ 3" 11.5mm/.452" 14,500 7/8" 3/8" Threaded Rod



Download Product Brochure
Download Safety Data Sheet
Download Hot-Rod Helpful Hints
Download Hot-Rod How To Use
Download Blade Selection Guide
Download Cutting System Overview
Download Product Flyer

More Information
SKUT-ALPH HR
Non-ReturnableNo
ManufacturerAlpha Tools
Warranty30 Days Parts/Labor
Manufacturer Part NumberHR03A+
Blade TypeSegmented Rim
Arbor Size 7/8", 20mm
No Load Speed (rpm)14,500
Ceramic Tile PerformanceNot Recommended
Porcelain Tile PerformanceNot Recommended
Glass Tile PerformanceNot Recommended
Marble PerformanceExcellent
Diameter3"
Thickness.165" - .452"
Wet or DryWet or Dry
Dimensions (L x W x H)3" x 3" x .165" - 3" x 3" x .452"
Weight (lbs.)0.36 - 0.98
