Schluter DITRA and DITRA-XL are polyethylene membranes designed for ceramic and stone tile installations. They provide uncoupling, waterproofing, vapor management, and load distribution, helping prevent tile cracking and protect moisture-sensitive substrates.
Schluter DITRA & DITRA-XL Membrane: Uncoupling and Waterproofing Protection
Schluter-DITRA and DITRA-XL are polyethylene uncoupling and waterproofing membranes designed for ceramic and dimension stone tile installations. Their unique grid structure features square, dovetail-shaped cavities and an anchoring fleece that creates a mechanical bond with the substrate through thin-set mortar.
The membranes perform four essential functions: uncoupling, waterproofing, vapor management, and load distribution. The open rib structure accommodates substrate movement, helping prevent tile cracking and delamination. Their waterproof polyethylene construction protects moisture-sensitive substrates, while integrated channels allow excess moisture and vapor to escape.
Mortar-filled cavities form column-like structures that transfer loads from the tile covering to the substrate, providing reliable support without compromising uncoupling performance.
Compatible with plywood, OSB, concrete, gypsum, and heated floors, DITRA provides a versatile installation solution. Its 1/8" (3.5 mm) thickness also helps minimize overall floor height.
Note: DITRA and DITRA-XL are intended for interior use only, in both dry and wet areas.
Key Features and Benefits
Effective Uncoupling Protection The open rib structure accommodates in-plane movement between the substrate and tile, reducing the risk of cracking and delamination
Reliable Waterproofing The polyethylene composition creates a waterproof layer that protects moisture-sensitive substrates from water penetration
Integrated Vapor Management Built-in channels allow excess moisture and vapor to escape from beneath the tile covering, helping prevent moisture-related damage
Superior Load Distribution Square cavities filled with mortar create column-like structures that transfer loads to the substrate while maintaining tile support
Strong Mechanical Bond The anchoring fleece underneath embeds into thin-set mortar, while the dovetail-shaped cavities mechanically anchor the mortar beneath the tile
Wide Substrate Compatibility Suitable for plywood, OSB, concrete, gypsum, and heated floor systems. DITRA also supports tile installations over single-layer plywood or OSB subfloors with joists spaced up to 19.2" (488 mm) on center
Low-Profile Installation DITRA features a 1/8" (3.5 mm) thickness, helping minimize floor assembly height and simplify transitions to adjacent flooring
Specifications
Property
Value
Item #
DITRA5M, DITRA150, DITRA-XL/175 (rolls); DITRA30M-LF, DITRA-XL/175-LF (by the linear foot)
Material
Polyethylene with fleece on the underside
Thickness
DITRA 1/8" (3.5 mm); DITRA-XL 5/16"
Width
3'3"
Sold by the linear foot
DITRA and DITRA-XL, 3'3" wide, cut to the length you order
Full rolls
DITRA 3'3" x 16'5" (54 sq ft); DITRA 3'3" x 45'9" (150 sq ft); DITRA-XL 3'3" x 53'3" (175 sq ft)
Minimum tile size
2" x 2"
Installation Tips
The substrate must be clean, even and load bearing; remove anything that would stop the mortar from bonding.
DITRA: use a 1/4" x 3/16" V-notch, a 5/16" x 5/16" V-notch or the DITRA trowel (11/64" x 11/64" square notch). DITRA-XL: use a 1/4" x 1/4" square-notch trowel or the DITRA-XL trowel.
Lay the membrane fleece side down into fresh thin-set and embed it with a float or the DITRA-ROLLER. Lift a corner to check that the fleece is fully covered; butt the edges of adjacent sheets.
Fill the cavities with Schluter SET, ALL-SET, FAST-SET or unmodified thin-set mortar, then set the tile.
Full installation steps and warranty conditions are in the DITRA Installation Handbook below.
